– Cover: Stainless steel AISI 304
– Pump body: Cast iron EN GJL 200 (UNI EN 1561)
– Impeller: Cast iron EN GJL 200 (UNI EN 1561)
– Seal motor side: Seal ring
– Mechanical seal pump side: Ceramics/Graphite
– Stator housing: Stainless steel AISI 304
– Motor shaft: Stainless steel AISI 420
– Bolts and nuts: Stainless steel Grade A2
– Feeding cable: single-phase version with 10 meters type H07RN-F 3G1mm² cable and SCHUKO plug (CEE 7/VII), three-phase version with 4G1mm² cable
– Max. temperature of the liquid pumped: +35°C
– pH of the liquid pumped: 6÷10
– Max. immersion depth: 5m
– Density of the liquid pumped: 1.100 kg/dm³
– Min. immersion for continuos service: DVX 8-10 370mm, DVX 15-20 400mm
– Free passage: 30-40 mm
– Max. number starts/hour: 20
– Acoustic pressure level issued: <70dB(A)
– The electric motor is asynchronous 2 poles with squirrel cage rotor in oil bath
– Class of insulation F, Protection degree IP68
– Single-phase built-in overheating protection and float switch
– Single-phase voltage: 230V/50Hz ±6%
– Three-phase voltage: 230V-400V/50Hz ±6%
– Other voltages on request
– With food grade white oil
– Silicon carbide (SiC/SiC) mechanical seal on request
